FILL-RITE Piston Drum Hand Pump

FILL-RITE Piston Drum Hand Pump

The Fill-Rite FR110 Rotary Hand Pump is especially effective with medium viscosity liquids as well as oils, gasoline and diesel fuels.  The rotary action of these easy-to-use pumps allows for smooth and continuous fuel transfer.

• Max Flowrate:  37.8 Liters Per 100 Revolutions
• Power Type:  Hand-Operated
• Compatible Fluids:  Diesel, Gasoline, Kerosene, Mineral Spirits, Heptane, Stoddard Solvents
• Inlet Size / Connection / Thread:  25.4mm / Female / NPT
• Outlet Size / Connection / Thread:  19.05mm / Female / NPT
• Mounting Size / Thread / Type:  50.8mm / NPT / Bung Mount
• Duty Cycle (min):  Continuous Duty

FEATURES:

• Aluminium body with cast iron rotor.
• UL listed.
• Supplied complete with 2.4m of UL listed hose with static wire.
• Check valve.
• Vacuum breaker.

DIMENSIONS:

• Assembled Product Height x Width x Depth (mm): 381 x 165.1 x 228.6
• Assembled Product Weight (kg): 4.3
• Package Height x Width x Depth (mm): 166.6 x 330.2 x 397
• Gross Weight (kg.): 4.8
